Other Rotary Screw Air Compressor
(Two Stage)
| Model | MFD-280A |
| Horsepower (HP) | 375 |
| Power (KW) | 280 |
| Air delivery / Discharge pressure (m3/min) / (Mpa) | 60.0/0.7 |
| 57.0/0.8 | |
| 49.5/1.0 | |
| 43.0/1.25 | |
| Weight(kg) | 8550 |
| Pipe diameter of outlet | DN125 |
| Remarks | Fix-speed two stage type |
MFD-315A 422HP Fixed Speed Rotary Screw Air Compressor
(Two Stage)
| Model | MFD-315A |
| Horsepower (HP) | 422 |
| Power (KW) | 315 |
| Air delivery / Discharge pressure (m3/min) / (Mpa) | 67.0/0.7 |
| 62.0/0.8 | |
| 56.0/1.0 | |
| 51.0/1.25 | |
| Weight(kg) | 9000 |
| Pipe diameter of outlet | DN125 |
| Remarks | Fix-speed two stage type |
MFD-355A 476HP Fixed Speed Rotary Screw Air Compressor
(Two Stage)
| Model | MFD-355A |
| Horsepower (HP) | 476 |
| Power (KW) | 355 |
| Air delivery / Discharge pressure (m3/min) / (Mpa) | 73.0/0.7 |
| 69.0/0.8 | |
| 61.0/1.0 | |
| 54.0/1.25 | |
| Weight(kg) | 10000 |
| Pipe diameter of outlet | DN125 |
| Remarks | Fix-speed two stage type |
