268HP Rotary Screw Air Compressor
(Single Permanent Magnet Motor Drive)
| Model | MDE-200A |
| Horsepower (HP) | 268 |
| Power (KW) | 200 |
| Air delivery / Discharge pressure (m3/min) / (Mpa) | 42.5/0.7 |
| 41.5/0.8 | |
| 37.0/1.0 | |
| 32.0/1.25 | |
| Weight(kg) | 4700 |
| Pipe diameter of outlet | DN100 |
| Remarks | One PM motors two -stage type |
MFD-200A 268HP Fixed Speed Rotary Screw Air Compressor
(Two Stage)
| Model | MFD-200A |
| Horsepower (HP) | 268 |
| Power (KW) | 200 |
| Air delivery / Discharge pressure (m3/min) / (Mpa) | 40.9/0.7 |
| 40.4/0.8 | |
| 37.0/1.0 | |
| 35.0/1.25 | |
| Weight(kg) | 4700 |
| Pipe diameter of outlet | DN100 |
| Remarks | Fix-speed two stage type |
